Professional vacuum cleaners

Floor scrubber-dryer 65 RD 55 BC

PRODUCT IDENTIFICATION
CODE MODEL/PALETTE
RUSH 65 RD 55 10.0665.00 1
RUSH 65 RD 55 BC 13.0665.00 1
RUSH 65 RD 55 BC LITHIUM 14.0665.90 1
FEATURES
Scrubbing path width 530mm
Suction width 750mm
Hourly output (theoretical - practical) m²/h 3200 - 1920
Power supply 24V Battery
Installed power W 1153
Movement advancement rear wheel drive
BATTERIES
Type Set of 2 x 12V gel batteries
105Ah (*) - Lithium battery
24V 100Ah (**)
Autonomy h - min 3 hours and 20 minutes (*) -
3 hours 10 min (**)
Battery compartment dimensions x number mm x nr 360x350x325 X 1
BRUSH
Pad diameter x number mm - inches
x nr.
530 - 21" x 1
Motor power x number W x nr 500 x 1
Motor speed rpm. 165
Head weight - specific pressure Kg - g/cm² 20;30.5 - 13;21
TRACTION
Motor power W 220
Max forward speed Km/h 6
Max gradient that can be overcome with full load % 2
Max gradient that can be overcome when empty % 12
SUCTION
Motor power W 385
Depression (water column) mbar -
mmH2O
107 - 1070
Air flow l/s 45
Noise dB(A) 63/57 (***)
TANK
Dual tank typology
Solution capacity l 65
Recovery capacity l 68
Weight (empty - with batteries) Kg 110 - 181 (*) - 138 (**)
Dimensions mm 1298x750x1185
SUPPLIED ACCESSORIES
MODEL CODE
Water inlet hose 30.0024.00
Polypropylene brush 21" Ø 0.7 40.0003.00
Diffuser Solution Brush 96.0207.00
Mudguard 96.0226.00
Set of natural rubber squeegees (front/rear) 96.0228.00
Set of 2 x 12V 105Ah gel batteries (*) 22.0724.00
On-board battery charger 24V 13A (*) 18.0095.00
Lithium battery 24V 100Ah (**) 18.0112.00
18.0113.00
CODE
Polypropylene brush 21'' Ø 0.9 40.0103.00
Polypropylene brush 21'' Ø 1.2 40.0303.00
Tynex brush 21'' Ø 1.2 grit 80 40.0203.00
Drive disk 485 mm (for 20" pad) 40.1003.01
Set of polyurethane squeegees (front/rear) 96.0228.01
Chemical mixing system 96.0227.00
Headlight kit 96.0180.00
Ignition kit 96.0229.00
Water stop kit 96.0183.00

Floor Scrubber-Dryer ROYAL 15 M38

Floor washer dryer - FR30

SPECIFICATIONS
Cleaning width 430mm
Squeegee width 650mm
Productivity (theoretic/practical) 1720 - 1030m²/h
Power supply 24 V Battery
Installed power 750w
BATTERIES
Battery set TypeGel (2 pcs) 12 V 76 Ah
Operating time - min 2 hours and 15 min
Battery compartment dimensions x Nomm x No 340x340x240 x 1
BRUSH
Disc diameter x Nomm - inches x no. 430 - 17” x 1
Motor rating x Now x no. 350 x 1
Motor speed 190
Down pressure - Contact pressure Kg - g /cm² 18 - 17.4
TRACTION
Motor rating W---
Driving speed Km/h 4
VACUUM
Motor rating W 400
Vacuum bar - mmH2O 28
Noise level B(A) 64 - 58 (silent mode)
TANK
Type Double tank
Cleaning solution tank 30l
Recovery tank 33
Weight (empty - with batteries) 68 kg - 121
Dimensions mm 1210x560x1020

Floor scrubber-dryer

ROLLY NRG 7½ M 33 pes 10 AH

TECHNICAL DATA

FEATURES
Cleaning width 330 mm
Squeegee width 420mm
Productivity (theor./practical) 1320 - 800m²/h
Power supply 24 V battery
Installed power W270
Advancement Manual
IP Code IPX3
BATTERIES
Battery type Lithium 24V 280Wh
Running time - min 1
Battery compartment dimensions x Nomm x No ---
BRUSH
Pad diameter x Nomm - inch x no 80 - Cyl. x 1
Motor rating x Now x no 120 x 1
Motor speed rpm 800
Contact pressure /cm² 35 - 71 - 160
TRACTION
Motor rating W---
Driving speed Km/h4
Hill climbing capability (full load)% 2
VACUUM
Motor rating W150
Vacuum mbar - mmH2O 48 - 490
Air flow rate l/s 30
Noise level dB(A) 58 / 54 (silent mode)
TANK
Type Double tank
Detergent tank 7,5l
Recovery tank 8
Weight (empty - with battery) Kg23 - 25,4
Power cable ---
Dimensions mm640x450x422

Professional floor cleaning machine (marble, tile, etc.)

SB 143 L 10
Technical data
TECHNICAL DATA
Working width - Ø brushmm
430
Brush speedrpm
154
VoltageV
220 - 240
Frequency Hz
50
Brush motor rating W
1000
Brush contact pressure g/cm²
40.3
Height under drive mm
330
Dust extraction attachment
yes
Noise level bA
<54
Transmission
planetary gearbox
IP code
IPX4
Power supply cable
12
Weight (without accessories) kg
41
Dimensions mm
1200x542x430
